5-11
5.3 Main Menu
Open the Main Menu to check or change settings.
The Main Menu can be invoked by pressing the key on any screen.
As delivered the language is English. To change to Japanese, Refer to “5.3.10 Language Settings
(LANGUAGE)".
1. Press the keys to move the cursor and select an item.
2. Press the key to display the menu for the selected item.
The following menus are available.
• DISPLAY: Displays settings menu for screen settings such as contrast and brightness.
(Refer to 5.3.1)
• HEADING: Displays settings menu for heading alignment related settings. (Refer to 5.3.2)
• GPS: Displays settings menu for GPS related settings. (Refer to 5.3.3)
• SBAS: Displays settings menu for SBAS related settings. (Refer to 5.3.4)
• BEACON: Displays settings menu for beacon related settings. (Refer to 5.3.5)
• SYSTEM: Displays settings menu for system related settings. (Refer to 5.3.6)
• DATA I/O: Displays settings menu for input and output port (data) related settings. (Refer
to 5.3.7)
• VERSION INFO: Displays program version of display unit and sensor. (Refer to 5.3.8)
• OTHERS: Displays settings menu for other miscellaneous settings. (Refer to 5.3.9)
• LANGUAGE: Displays Language Settings Menu. (Refer to 5.3.10)
Main Menu
Procedure
Settings confirmation
(Items setting changes
cannot be performed.)
To alter the settings of these
items go to Maintenance
Mode.
(Refer to 5.4)
To Next Page
