9-3
9.2 SENSOR UNIT (NNN-20/30)
9.2.1 Electrical Specifications
(1) Reception Method: Multichannel all in view (12CH + SBAS 1CH)
(2) Reception Frequency: 1575.42MHz ± 1MHz (C/A code)
(3) Positional Accuracy: 0.3º RMS (NNN-30)
0.5º RMS (NNN-20)
(4) Tracking Rate of Turn: 45º / sec.
(5) Tracking Acceleration: 1G
(6) Power Supply Voltage: DC12/24V (+30%, -10%)
(7) Power Consumption: Maximum 5.5W
9.2.2 Environment
(1) Operating Temperature: -25ºC +55ºC
(2) Storage Temperature: -25ºC +70ºC
(3) Waterproofing: IPX6
(4) Vibration: IEC60945 ed.4 conformant
(5) EMC: IEC60945 ed.4 conformant
9.2.3 Dimensions and Mass
(1) Dimensions: NNN-30 φ1152 x 286 mm
NNN-20 φ691 x 285 mm
(2) Mass: NNN-30 Approximately 9.5 kg
NNN-20 Approximately 6.2 kg
(3) Cable: 10 m
