7.1.4 Range Adjustment
Adjust the range so that the range of the target on the radar video is indicated correctly.
Procedure 1 Search the radar display for a target of
which range is already known.
2 Hold down [RADAR MENU] key.
The Code Input Menu will appear.
3 Press [0] key.
4 Move the cursor onto the “ENT” button
in the Code Input menu, and press
[ENT] key.
The Adjust Menu will appear.
5 Press [1] key.
Equipment Setup menu opens.
6 Press [2] key.
The Code Input Menu will appear.
7 Using numeric pad, enter the value and then press “ENT” button, and
press “EXIT” button to determine the value.
The multi-function control can also be used to enter the value.
8 Repeat step 4, and adjust until the target range measured in step 1 and
the range on the radar display become identical.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
