11.3 JMA-5209 TYPE RADAR
(1) Class of Emission P0N

(2) Display Color Raster Scan
(3) Screen 15-inch Color LCD
Effective diameter of radar display, more than 180 mm
(4) Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96nm
(5) Range Resolution Less than 30m
(6) Minimum Detective Range Less than 40m
(7) Range Accuracy Less than 1% of the maximum distance of the range scale in use or
less than 15m whichever is larger
(8) Bearing Accuracy Less than 1r
(9) Bearing Indication Relative Motion mode: Head-up/Course-up/North-up
True Motion mode: Course-up/North-up
(10) Ambient Condition According to IEC60945-4
Temperature
Scanner: -25 to +55Υ
(Storage Temperature: -25 to +70Υ)
Other Units except Scanner: -15 to +55Υ
Relative Humidity 93% at +40Υ
Vibration 2 to 13.2Hz, amplitude s1mm s10%
13.2 to 100Hz, acceleration 7m/s
2
Velocity of the wind 51.5m/s(100kt)
(11) Power Supply Input +12/24/32VDC (Display Unit)
+12/24/32VDC (Scanner)
* Display Unit and Scanner correspond to
100/110/115/220/230/240VAC, 1
M , 50/60Hz
when use NBA-5111
(12) Power Consumption Approx. 220W (In maximum wind velocity)
(13) Power Supply Voltage +12V/24V/32VDC +10.8 to 41.6VDC (Display Unit)
Fluctuation +12V/24V/32VDC +10.8 to 41.6VDC (Scanner Unit)
(14) Pre-heating Time Approx. Within 1min30sec
