8.3 PERFORMANCE CHECK
ņ20
8
yyyy
yyyy
8.3.1.7 MAGI
Displays the MAGI bar indicating the magnetron current to check.
Procedure 1 Check if the MAGI bar in the Test Menu
reads the value below in a range of 24
NM.
6 kW: 4 to 5 scale marks
10 kW: 4 to 7 scale marks
25 kW: 6 to 9 scale marks
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
