9.2.2 Special Parts

Table 9-8 Special Parts

[I] JMA-5204

Parts No. Name Type Manufacturer Location Code

V101 Magnetron MSF1421B NJRC Scanner 5VMAA00092

A101 Circulator FCX68R Orient Microwave Scanner 5AJIX00027

A102 Diode Limiter NJS6930 NJRC Scanner 5ATBT00006

[II] JMA-5208/HS

Parts No. Name Type Manufacturer Location Code

V101 Magnetron MSF1422B NJRC Scanner 5VMAA00068

A101 Circulator FCX68R Orient Microwave Scanner 5AJIX00027

A102 Diode Limiter NJS6930 NJRC Scanner 5EZAA00024

[III] JMA-5209

Parts No. Name Type Manufacturer Location Code

V101 Magnetron MSF1422B NJRC Scanner 5VMAA00090

A101 Circulator FCX68R Orient Microwave Scanner 5AJIX00027

A102 Diode Limiter NJS6930 NJRC Scanner 5ATBT00006

[IV] JMA-5212-4/6/4HS/6HS

Parts No. Name Type Manufacturer Location Code

V101 Magnetron MAF1565N NJRC Scanner unit 5VHAA00102

A101/A102 Circulator FCX68R OrientMicrowave Scanner unit 5AJIX00027

A103 Dummy NJC4002 NJRC Scanner unit 5ANDF00001

A104 Filter NJC9952 NJRC Scanner unit 5AWAX00002

A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006

[III] JMA-5222-7/9

Parts No. Name Type Manufacturer Location Code

V1 Magnetron M1568BS NJRC Scanner unit 5VMAA00106

A101/A102 Circulator NJC3901M NJRC Scanner unit 5AJBV00007

A103 Dummy NJC4002 NJRC Scanner unit 5ANDF00001

A104 Filter NJC9952 NJRC Scanner unit 5AWAX00002

A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006
