7.2 NAVIGATOR SETTING

ņ22

yyy

yyyy

1 Hold down [RADAR MENU] key.

The Code Input Menu will appear.

2 Press [0] key.

3 Move the cursor onto the “ENT” button in the Code Input menu, and

press [ENT] key.

The Adjust Menu will appear.

4 Press [6] key.

NAV Equipment Setting menu opens.

5 Perform steps 3 to 8 in the “Procedure” above.

Exit 1 Press [RADAR MENU] key.

The menu will be closed.
