Table 8-2 System alarm warning list 1: Scanner
Message Class Description ALR No.
TXRX(AZI) Alarm Scanner: Rotation signal (BP) error. 311
TXRX(Data) Alarm Scanner: Communication data error, checksum error or data mismatched. 901
TXRX(Fan 1) Alarm Scanner: FAN 1 error. 320
TXRX(Fan 2) Alarm Scanner: FAN 2 error. 902
TXRX(Heater) Alarm Scanner: Magnetron heater voltage error. 314
TXRX(HL) Alarm Scanner: Reference rotation signal (HL) error. 312
TXRX(MHV) Alarm Scanner: Modulator's high voltage alarm. 315
TXRX(Motor) Alarm Scanner: Motor current error. 317
TXRX(Reverse) Alarm Scanner: Reverse rotation. 313
TXRX(SSW Off) Alarm Scanner: Safety switch OFF. 308
TXRX(Time Out) Alarm Scanner: No communication. 326
TXRX(Trigger) Alarm Scanner: TRIGGER error. 310
TXRX(Video) Alarm Scanner: VIDEO error. 309
ALR No: Unique alarm number in ALR sentence and ACK sentence.
Table 8-3 System alarm warning list 2: Display
Message
Class Description ALR No.
AIS PROC(Data) Alarm AIS processing circuit: Communication data error or checksum error. 919
AIS PROC(Time Out) Alarm AIS processing circuit: No communication. 328
Indicator(Fan) Alarm LCD monitor: FAN error. 905
Keyboard(Data) Alarm
Operation unit: Communication data error, checksum error or data
mismatched.
906
Keyboard(Time Out) Alarm Operation unit: No communication. 325
Keyboard2(Data) Alarm
Second operation unit: Communication data error, checksum error or
data mismatched.
908
Keyboard2(Time Out) Alarm Second operation unit: No communication. 907
PROC(AZI) Alarm Process unit: Rotation signal error. 305
PROC(HL) Alarm Process unit: Reference rotation signal error. 306
PROC(Interrupt) Alarm Process unit: Interrupt error. 913
PROC(Reverse) Alarm Process unit: Reverse rotation error. 307
PROC(Trigger) Alarm Process unit: Trigger error. 304
PROC(Video) Alarm Process unit: VIDEO error. 303
ALR No: Unique alarm number in ALR sentence and ACK sentence.
