1.3 Configuration
y
1
1.3 CONFIGURATION
Specified of scanner, and categories of ship/craft for SOLAS V
Radar Model Antenna Type
Transmitted
Output Power
Band Rate of Rotation Category
JMA-5312-6 6 ft slot antenna 10 kW X 27 rpm CAT 2
JMA-5312-6HS 6 ft slot antenna 10 kW X 48 rpm CAT 2H
JMA-5322-7 7 ft slot antenna 25 kW X 24 rpm CAT 2
JMA-5322-9 9 ft slot antenna 25 kW X 24 rpm CAT 2
JMA-5322-6HS 6 ft slot antenna 25 kW X 48 rpm CAT 2H
JMA-5332-12 12 ft slot antenna 30 kW S 24 rpm CAT 2
*The class of emission: P0N (All scanner types)
Radar Configuration and Ship’s Mains
Radar Model Scanner Unit
Performance
Monitor (option)
Display Unit Ship’s Mains
JMA-5312-6 NKE-2103-6 NJU-85 NCD-4530 DC24 V
JMA-5312-6HS NKE-2103-6HS NJU-85 NCD-4530 DC24 V
JMA-5322-7 NKE-2254-7 NJU-85 NCD-4530 DC24 V
JMA-5322-9 NKE-2254-9 NJU-85 NCD-4530 DC24 V
JMA-5322-6HS NKE-2254-6HS NJU-85 NCD-4530 DC24 V
NCD-4530
DC24 V (supplied from
NBA-5111)
AC100-115 V, 50/60 Hz, 1 φ
JMA-5332-12 NKE-1130 NJU-84
*NQE-3151A
AC220-240 V, 50/60 Hz, 1 φ
* The NQE-3151A included in JMA-5332-12 is a connection unit to supply AC power for the motor to
the scanner unit.
Notes:
1. The JMA-5332-12 needs AC power for the radar process unit (rectifier unit NBA-5111), and motor
to drive the scanner unit.
2. The drive motor for the scanner unit is available in AC100-115 V or AC220-240 V type for
JMA-5332-12. Please specify the motor type when ordering.
3. An optional POWER SUPPLY NBA-5111 is necessary for using Ship's Mains
AC100-120/220-240 V, 50/60 Hz, 1 φ.
4. When using the ship's mains of AC440V as the radar power source, a step-down transformer shall
be used.
5. The scanner unit except NKE-2103 series can be equipped with a deicing heater as an option, and
'-D' shall be suffixed to the type name. (e.g. NKE-1130-D, NKE-2254-6D).
1-4
