5－24
JMA-9100 Instruction Manual > 5.OPERATION OF TARGET TRACKING AND AIS > 5.2 TARGET TRACKING OPERATION
5.2.7.2 Target Tracking Simulator (Target Tracking Simulator)
Pseudo targets can be generated in certain known positions to check whether the
target tracking units are operating normally. Since the pseudo targets move
depending on known parameters, the values for these pseudo targets can be
compared with the known value if the pseudo targets are acquired and tracked,
and displayed. Thus, it can be checked if the system is operating normally.
Procedures
1) Press the [TX/STBY] key to stop the transmitting.
The equipment will enter the transmission standby state.
2) Open the TT Test Menu by performing the following menu
operation.
→
3) Left-click the item button of .
The setting items for TT Simulator will be displayed.
4) Select the scenario to be set.
The TT Simulator display will be turned on.
5) Press the [TX/STBY] key to transmit.
When the TT simulator is active, the character " X " will display at the bottom of the radar
display.
Target tracking simulator / scenario
Scenario Target start point Target end point Pseudo-target
speed
Distance Bearing Distance Bearing
1 3.2NM 20° 1NM 90° 20kn
2 6NM 0° 0NM 0° 10kn
3 6NM 18° every 1NM 18° every 10kn
4 6NM 45° 1NM 45° 105kn
5 6NM 45° 6NM 150° 20kn
6 6NM 45° 6NM 150° 20kn
i
When the simulator is operating, set 0° as the heading bearing,
and 0 kn as the speed of own ship.When the range between
own ship and the pseudo target is 0, the target will disappear.
TT
9. TT Test Menu
2. TT Simulator
