A.2.4 Change of Connection Pattern (with 3 or More Display
Units)
If three or more display units are installed, the layout of connection patterns needs
to be set.
Procedures
1) Open the Inter Switch Menu (with 3 or More Display Units).
2) Move the cursor onto the display unit (Section b. "Display unit connected as
master" or Section c. "Display unit connected as slave")
to be changed , and left-
click.
The selected display unit will be highlighted.
To deselect the display unit, left-click key again.
3) Move the cursor to the change-destination display unit, and left-
click.
he selected display unit in step 2 will be switched to the change-destination display unit, and
(Section f. "Set") will blink.
If the change destination is empty, control will move and will blink.
4) Left-click the button.
The connection pattern will be changed.
A master display unit is always necessary for establishing a
slave connection.
3. Set
3. Set
3. Set
