C.9 Serviceman Menu
├Serviceman Menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - section 7.1.1 on page 7-1
├ 1. Adjust Menu
│├1. Tune Adjustment - - - - - - - - - - - - - - - - - - - - - - - -
section 7.1.3 on page 7-5
│├2. Bearing Adjustment - - - - - - - - - - - - - - - - - - - - - - - section 7.1.4 on page 7-7
│├3. Range Adjustment - - - - - - - - - - - - - - - - - - - - - - - - section 7.1.5 on page 7-7
│└4. TXRX Adjustment
││├1. Antenna Height - - - - - - - - - - - - - - - - - - - - -
section 7.1.8 on page 7-9
││├2. Tune Peak Adjustment- - - - - - - - - - - - - - - - - section 7.1.3.2 on page 7-5
││├3. Tune Indicator Adjust - - - - - - - - - - - - - - - - - section 7.1.3.3 on page 7-6
││├4. MON Adjustment - - - - - - - - - - - - - - - - - - section 7.3.4.1 on page 7-37
││├5. MON Indicator Adjustment - - - - - - - - - - - - - - section 7.3.4.2 on page 7-38
││└6. Output Pulse - - - - - - - - - - - - - - - - - - - - - section 7.2.4 on page 7-18
├ 2. Installation Menu
│├1. Installation Information - - - - - - - - - - - - - - - - - - - - -
section 7.2.8 on page 7-21
││├1. Date
││├2. Name
││└3. Company
│├2. Master/Slave - - - - - - - - - - - - - - - - - - - - - - - -
section 7.2.5.1 on page 7-19
│├3. Sector Blank- - - - - - - - - - - - - - - - - - - - - - - - - - section 7.2.2 on page 7-16
││├1. Sector1 - - - - - - - - - - - - - - - - - - - - - - - section 7.2.2.1 on page 7-16
││├2. Sector2 - - - - - - - - - - - - - - - - - - - - - - - section 7.2.2.1 on page 7-16
││├3. Sector3 - - - - - - - - - - - - - - - - - - - - - - - section 7.2.2.1 on page 7-16
││├4. Make Sector1 - - - - - - - - - - - - - - - - - - - - section 7.2.2.2 on page 7-16
││├5. Make Sector2 - - - - - - - - - - - - - - - - - - - - section 7.2.2.2 on page 7-16
││└6. Make Sector3 - - - - - - - - - - - - - - - - - - - - section 7.2.2.2 on page 7-16
│├4. CCRP Setting - - - - - - - - - - - - - - - - - - - - - - - - - section 7.1.9 on page 7-10
│├5. COM Port Setting - - - - - - - - - - - - - - - - - - - - - - - section 7.2.1 on page 7-12
││├1. Baud Rate - - - - - - - - - - - - - - - - - - - - - - section 7.2.1.1 on page 7-12
│││├1. COMPASS
│││├2. MAINTENANCE/LOG
│││├3. NAV1
│││├4. NAV2
│││├5. ALARM
│││├6. JARPA
│││├7. AIS
│││├8. BRIDGE NET
│││├9. Next
│││├1. ARPA
│││└2. COM
││├2. RX Port - - - - - - - - - - - - - - - - - - - - - - -
section 7.2.1.2 on page 7-13
│││├1. GPS
│││├2. DLOG
│││├3. Alarm
│││├4. Depth
│││├5. Temperature
│││├6. Wind
│││├7. Current
│││├8. ROT
│││├9. Next
│││└1. RSA
││├3. RX Sentence - - - - - - - - - - - - - - - - - - - -
section 7.2.1.3 on page 7-14
│││├1. GPS(LL/COG/SOG)
│││├2. GPS(WPT/TIME)
│││├3. Depth
│││├4. Wind
│││└5. Current
││││├1. Data Set Number
││││├2. Layer A
││││├3. Layer B
││││└4. Layer C
││├4. TX Port - - - - - - - - - - - - - - - - - - - - - - -
section 7.2.1.4 on page 7-15
│││├1. TTM(TT)
│││├2. TLL(TT)
