JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.20 PERFORMANCE MONITOR (NJU-84)
11.20 PERFORMANCE MONITOR (NJU-84)
11.21 PERFORMANCE MONITOR (NJU-85)
11.22 AC/DC CONVERTER (NBA-5135)
Accuracy of Display
Complied with IMO Requirement
System Failure Alarm
Visible / Audible Alarm
Speed Input Auto (LOG)
PERFORMANCE MONITOR NJU-84
Dimension Width 130 x Depth 180 x Height 70 (mm)
Mass Approx.0.7kg
Operating Frequency
3050±30MHz
PERFORMANCE MONITOR NJU-85
Dimension Width 130 x Depth 149 x Height 70 (mm)
Mass Approx.0.7kg
Operating Frequency
9410±30MHz
AC/DC CONVERTERNBA-5135
Dimension Width 315 x Depth 385 x Height 99 (mm)
Mass Approx.5kg
Power supply Input AC100 to 240V, 50/60Hz, 1φ
Output Voltage DC24V +/-5%
Output Current 12A max
