JMA-9100 Instruction Manual > A.NQE-3141 Interswitch Unit > A.2 INTERSWITCH OPERATION
Aļ¼9
A
[3] Erasing a connection pattern (Erase)
Procedures
1) Open the Inter Switch Menu (with 3 or More Display Units).
2) Left-click the button.
The File Operations window will appear.
3) Left-click the button.
The Erase menu will appear.
The list of connection patterns stored in the memory will be displayed.
4) Left-click the button corresponding to the file to be erased.
Confirmation Window will appear.
5) Left-click the to load.
The selected connection pattern is erased and the file name is deleted from the list.
A.2.6 Names of Display Units and Scanner Units
The display units and antenna units can be named.
Procedures
1) Open the Inter Switch Menu (with 3 or More Display Units).
2) Left-click the button.
"Name" will be highlighted, indicating that the rename mode is activated.
3) Move the cursor to the display unit (Section b. "Display unit connected as
master" or Section c. "Display unit connected as slave")
or scanner unit (Section a.
"Connected scanner unit")
to be renamed , and left-click.
he Input IND Name or the Input TXRX Name window will appear.
4) Input a new unit name.
Up to 8 characters can be input as a unit name. For the input method on the character input
menu, see Section 3.3.4.7 "Entering a character".
The selected display unit or antenna unit will be renamed when the new name is input.
2. File Operation
3. Erase
1. Yes
1. Name
To Next Page
