JRC JUE-95SA - System Configuration Details; Cable Connection and Setup Example

2
2-1
Security buttons shall be installed in the navigation bridge and at least one other location. (SOLAS Chapter XI-1 Regulation 6) Up to four Security buttons can be connected to the Junction Box.
CHAPTER 2. Configuration
2.1 Cable connection and example of setting
PSU
Printer
Captain Room
Other Rooms
Bridge
Fig. 2.1 JUE-95SA Installation wiring diagram
Security
Button
Security
Button
Security
Button
IME
JB
Security
Button
DTE
TTYCS-1Q or equivalent
EME
(Option) (Option)
(Option) (Option)
