4-9
4
4.6 Countermeasure
If the equipment does not operate normally even following procedure is performed, please consult
JRC service agent.
Take care not to touch any parts PC board.
Abnormal operation of IME
In case of the heavy fluctuation of the voltage or frequency of the power source, or thunderbolt
and etc., IME may not operate normally. In this case, please try following procedure (a). And
try procedure (b) when procedure (a) did not work.
(a) Set
POWER switch to OFF, and confirm all of the LED lamps are lights out (it will takes
approximately 3 minutes) and set to ON again.
(b) Press
RESET button in the IME panel by the tip of narrow object (like extended clip,φ0.5mm).
Push until you feel the object clicks. (refer Fig. 4.6)
Five lamps (POWER lamp to RECEIVE lamp) lights in order, and starts blinking (it will takes
approximately 10 seconds). Turn on POWER switch with confirming these lamps are blinking.
The data, which are received message, call logging history and alarm history, memorized in IME are
cleared when RESET button is pushed. Saving important data to Floppy-Disk or USB Flash Memory is
highly recommended (Prepare optional DTE, Floppy-Disk Drive (for DTE (NDZ-127C1)), and JUE-85
instruction manual).
Procedure (b)
Push the RESET Button with a stick of
wire like extended clip.
The depth of the hole is approximately
1cm. So, use the wire 2cm or more.
Procedure (a)
Set
POWER switch to OFF and set to
ON again.
NOTE
Fig. 4.6 Reset of IME
