20
Servo Reversing (Function Mode)
The Servo Reversing feature of the XR2i is a very con-
venient feature when setting up a new model. The
purpose of the servo reversing function is to change
the direction of the servo rotation in relation to the
wheel/trigger movement. The Servo Reversing
function is available for the steering and throttle of
the XR2i.
Accessing the Servo
Reversing Function
1. Turn the transmitter power switch on.
2. Press the Scroll key to access Function mode.
3. Press the Scroll key until "REV.NORM" appears in
small letters to the right of the screen.
4. Press the Channel key to select the channel to be
changed (ST = Steering, TH = Throttle).
5. Press the Increase or Decrease keys to move the
cursor to the desired direction.
6. To exit the Function mode, either turn off the
transmitter power switch or press the Scroll and
Channel keys at the same time.
Current Channel
ST = Steering
TH = Throttle
AUX = Auxiliary
Channel 3
Current Servo
Direction
st
—
REV•NORM
Press the Channel key
to select the desired
channel to be adjusted.
STS = Steering
THS = Throttle
AUX = Auxiliary
Channel 3
Press the Mode key
until “REV. NORM”
appears on the screen.
Press the Increase or Decrease keys to move
the cursor to the desired servo direction.
SCROLL
ENTER
CHANNEL
INCREASE
CLEAR
DECREASE
To Next Page
