6
Transmitter XR2i
Receiver R-125
Servos Z590M x 1
Z270 x 1
Accessories BEC switch harness with
battery case, servo accessories
(for each servo),
instruction manual
R-125 Receiver
Z270 Servo
Components
Model number XR2i
Encoder 2-channel computer system
RF output 27MHz/75MHz
Modulation AM
Output power 195mW
Current Drain 150mA
Power source 1.5V x 8 dry cell
(1.2V x 8 Ni-Cd optional)
Output pulse 1000–2000 (1500 neutral)
XR2i Transmitter
Torque 49 ounce inch (@6.0V)
Speed .19 sec/60° (@6.0V)
Weight 1.5 oz
Size (WxLxH) 0.73" x 1.51" x 1.37"
Motor 3-pole ferrite
Torque 85 ounce inch (@6.0V)
Speed .15 sec/60° (@6.0V)
Weight 1.6 oz
Size (WxLxH) 0.73" x 1.55" x .146"
Motor 3-pole ferrite
Model number NER-125
Type 2-channel/AM
ABC&W circuitry
Frequency 27MHz/75MHz
Sensitivity 5qs minimum
(microseconds)
Selectivity 8 KHz/50dB
Weight 1 oz
Size (WxLxH) 1.25" x 1.75" x 0.81"
Receiver Antenna 20"
Power supply 4.8–6.0V DC
Z590M Servo
System Specifications
5189 JR XR-2i manual 9/18/02 12:01 PM Page 6
