9
Steering Tension Adjustment
Charging Jack
Steering tension is adjustable via the recessed screw
located beneath the steering wheel (see page 7 for
exact location). Turning the screw clockwise increas-
es the steering tension.
Charger Pigtail For Transmitter
Black To Positive
Red To Negative
JR TRANSMITTER CHARGE JACK POLARITY:
Located on the left-hand side of the transmitter is the
charging jack that accepts only JR wall chargers.
Please do not attempt to use any other brand of wall
charger, as it may be reverse polarity and can cause
damage to your system. Only use the JR wall charger
when the XR2i is equipped with Ni-Cd batteries
(JRPB958, available separately).
