25
Grip Lever A: Brake End-Point Adjustment BRK/Auxilary
Channel 3 Access
The Brake End-Point Adjustment, located at Grip Lever
A, allows the maximum servo travel on the braking side
of the throttle trigger to be increased or decreased
from 100% to 0% (off). This function is very useful in
race conditions as it allows the racer to custom tailor
the "panic" brake value to maximize the car's braking
power for the current track conditions. Please note
that since the Brake end-point value shown in the "BRK"
screen is a percentage of the total braking value
established in the End-Point Adjustment function
(page 24), the value will not always increase or
decrease each time the Grip Lever A is moved.
To adjust the brake end-point value, move the
electronic Grip Lever A either left (-) or right (+). As
soon as the grip lever is moved, the BRK End-Point
Adjustment screen will appear and will continue to
be displayed unless the Grip Lever A is untouched
for a period of two seconds.
Current Value
(100% to 0%)
brk
50
EPA
Move the grip lever A to the left or right to decrease or increase values.
R/B
Decrease
Increase
Grip Lever A
Brake Trim
To Next Page
