IV. Description of the Connectors
Output ports
The scale is designed with two output ports:
1. Bidirectional RS-232, which can be connected to PC, printer,
and a control box to output 3 section control signal
2. 9-pins connector for a remote platform.
Position of the connectors
Both of the connectors are located at the left side of the bottom
housing.
Location of the connectors
Remote platform
connector
RS232 connector
