Caution:

Always use the microphone with balanced output.

The microphone XLR input provides a 12V phantom

power supply.

4.4 Connecting a wireless microphone

1) Connect a wireless receiver to the microphone

XLR input of CU.

2) Adjust the sensitivity by using the gain control 1

*CS-1CU

4.5 External recording and playing

1) Connect a recorder to the recorder input and output

by two pairs of RCA cable.

2) Adjust the sensitivity by using the gain control 1
