– 80 –
3. Installation of the suction motor
(1) Fix the suction motor to the suction unit mounting plate by
means of the setscrews (6 positions).
(Refer to the illustration for the setscrew position.)
4. Installation of the suction pipe
(1) Install the suction pipe on the blower joint A section by means
of the hose bands .
(2) The suction pipe is connected to the filter box . Install this pipe
on the blower joint B section by means of the hose bands .
5. Suction pipe fixing
(1) Pinch the suction pipe with the cable clip bands and fix it by
means of the setscrew .
6. Suction wiring
(1) Fix the switch wiring by means of cable clips and the setscrews
as illustrated.
Adjustment Procedures Results of Improper Adjustment
To Next Page
