– 94 –
16. Adjustment of clamp stacker unit position
(1) For stacker unit adjustments, vertically move and adjust the base
collar by loosening the setscrew so that a dimension of 47mm
can be secured between the upper face of the sewing table and that
of the clamp base cushion.
(2) Adjust the stacker unit by loosening the stacker unit fixing screw
so that a dimension of 220mm can be secured between the end face
of the sewing table and that of the clamp base cushion.
17. Adjustment of clamp base cylinder air pressure
(1) Lower the regulator knob in the direction of Section A and turn it
for adjustment until a clamp base cylinder air pressure of 0.4MPa
can be secured.
After the completion of adjustment, raise the regulator knob in the
direction of the B section and secure the knob.
Adjustment Procedures Results of Improper Adjustment
To Next Page
