−42 −

Standard Adjustment

◎ Attaching parts list of the reverse feed control lever (List 2)

Note No. Part No. Name of part Q’ty

1 22656003 Lever spring suspension 1

2 SS4120615SP Lever spring suspension setscrew 1

3 11100500 Reverse feed control lever stopper 1

4 SS7112420SP Reverse feed control lever stopper setscrew 1

5 10120004 Lever return spring suspension 1

6 22656102 Reverse feed shaft link 1

7 SS7120760SP Reverse feed shaft link push screw 1

8 13515606 Lever return spring 1

9 WP0502616SD Reverse feed control lever stopper screw washer 1

◎ Attaching parts list of the automatic reverse feed device (List 3)

Note No. Part No. Name of part Q’ty

1 21348503 Reverse feed link installing base 1

2 21348701 Reverse feed link 1

3 SD0800352SP Reverse feed link hinge screw 1

4 PA320150200 Reverse feed cylinder 1

5 PJ301065104 Straight joint 1

6 PX015101000 Muffler 1

7 21348602 Cylinder connecting screw 1

8 SD0800352SP Reverse feed link hinge screw 1

9 NM6060003SC Cylinder connecting screw nut 1

10 21348909 Window plate B 1

11 SS7151210SP Reverse feed link installing base setscrew 2

12 WP0641601SD Reverse feed link installing base setscrew washer 2

13 SM6061602TP Reverse feed cylinder setscrew 2

◎ Attaching parts list of the touch-back switch (List 4)

Note No. Part No. Name of part Q’ty

1 21348859 Touch-back switch 1

2 SS7110840SP Switch installing plate setscrew 2

◎ Attaching parts list of the pneumatic components (List 5)

Note No. Part No. Name of part Q’ty

1 23105554 Pneumatic components (asm.) 1

2 SK3482500SC Pneumatic components setscrew 4

● Set part No. of the automatic reverse feed device

Note No. Part No. Name of part Q’ty

21348552 Automatic reverse feed device set 1

(Caution) This part No. means the set part No. of the parts from List 1 to List 5.
