−43 −

Installing procedure

6) Installing the touch-back switch

1. Install touch-back switch ① with switch installing plate setscrews ② .

Installing parts list

Note No. Part No. Name of part Q’ty

1 21348552 Automatic reverse feed device set 1

2 21348909 Side plate D 1

3 PA320150200 Reverse feed cylinder 1

4 SM6061602TP Reverse feed cylinder setscrew 2

5 WP0641601SD Reverse feed cylinder setscrew washer 2

6 21348602 Cylinder connecting screw 1

7 NM6060003SC Cylinder connecting screw nut 1

8 21348503 Reverse feed link installing base 1

9 SS7151210SP Reverse feed link installing base setscrew 2

10 21348701 Reverse feed link 1

11 SD0800352SP Reverse feed link hinge screw 2

12 PJ301065104 Straight joint 1

13 PX015101000 Muffler 1

14 SD0800402TP Reverse feed link hinge screw 1

15 NS6150430SP Reverse feed link hinge screw nut 1

16 22656102 Reverse feed shaft link 1

17 SS7120760SP Reverse feed shaft link push screw 1

18 22656003 Lever spring bracket 1

19 SS4120615SP Lever spring bracket setscrew 1

20 13515606 Lever return spring 1

21 10120004 Lever return spring bracket 1

22 11100500 Reverse feed control lever stopper 1

23 SS7112420SP Reverse feed control lever stopper setscrew 1

24 21348859 Touch-back switch 1

25 SS7110840SP Switch installing plate setscrew 2
