Julabo CF41 - 8.8. ATC Absolute Temperature Calibration

Menu functions
62
8.8. ATC Absolute Temperature Calibration, 3-point calibration
ATC serves to compensate a temperature difference that might occur between
Cryo-Compact Circulator and a defined measuring point in the bath tank
because of physical properties.
Main menu
Interface serial
Pump
>ATCalibration
ESC
ESC
ESC
1
1
ATCalibration
>Sensor : intern
Status : no /yes
Type : 3-point /1-point/2-point
TmpValue1: xx.xx°C
CalValue1: xx.xx°C
TmpValue2: xx.xx°C
CalValue2: xx.xx°C
TmpValue3: xx.xx°C
CalValue3: xx.xx°C
ATCalibration
>Sensor : extern
Status : no /yes
Type : 3-point /1-point/2-point
TmpValue1: xx.xx°C
CalValue1: xx.xx°C
TmpValue2: xx.xx°C
CalValue2: xx.xx°C
TmpValue3: xx.xx°C
CalValue3: xx.xx°C
internal
external
Sensor: >intern<, >extern<
Calibration can be carried out for the internal temperature sensor and
for the external temperature sensor connected to the socket „ext.
Pt100“.
The Cryo-Compact Circulator is able to store both parameter sets.
However, only the one set under this menu item is indicated.
Status:
>no< The controller of the Cryo-Compact Circulator uses the
original curve of the temperature sensor.
Important: During the calibration process >no< needs to be set.
>yes< The controller of the Cryo-Compact Circulator uses the
new calibration curve.
