Julabo CF41 - 8.5. Analog Inputs;Outputs

Menu functions
52
8.5. Analog inputs/outputs
ALARM
REG+
E-PROG
STAND-BY

In order to use the analog inputs and outputs, the Cryo-Compact
Circulator must be equipped with the electronic module available as
option.
Order No. 8 900 100 Electronic module
This submenu enables setting of the input and output values for the
programmer input and the temperature recorder outputs of socket
REG+E-PROG.
The >STAND-BY< input and the >ALARM< output are configurable.
 If the electronic module is not fitted, the item >inputs/outputs< will be
missing in the menu.
Main menu
Limits
Interface serial
>Input/Output
Inputs/Outputs
>Chan.1 : ActInt
EPROG : Setpoint
Ext.StBy : inactiv
Alarmout : StdBy
Chan.2 : Setpoint
Chan.3 : Power
Output Chan.1
tExt/Power/Setpoint
:
:
>Value of: ActInt /Ac
0V = -50.00°C
10V = 200.0°C
Output Chan.2
tExt/Power
:
:
>Value of: Setpiont /ActInt/Ac
0V 0.00°C
10V 100.00°C
Output Chan.3
tExt/ActInt
:
:
:
>Value of: Power /Setpoint/Ac
0mA 0%
20mA 100%
Region: 0-20mA /4-20mA
Input EPROG
(%)/FlowRate(L/min)
REM: % / L/min
REM: % / L/min
>Value as: Setpoint /Variable
Signal : Voltage /Current
H Value 200.00°C
Setpoint : xx.xx°C
AlarmOut
>Function: StdBy /Alarm/Al+StdBy
Type : normal /invers
ESC
ESC
1
1
1
ESC
Input Standby
>Status : inactiv /activ
1
L Value -50.00°C REM: % / L/min
