Always turn off the unit and disconnect the mains cable from the power source before
performing any service or maintenance procedures, or before moving the unit.
Configuration, installation, maintenance and repairs on the Cryo-Compact Circulator
• Turn off the unit with the mains switch and disconnect the
power plug.
• Open the screws (A) and remove the dummy plate.
• Carefully insert the upper edge (B) into the rear panel from
below, align the electronic module at top and bottom and
applying light pressure connect the 15-pole connector.
• Attach the electronic module using the screws (A).
• The Cryo-Compact Circulator is ready for use. It automatically
recognizes the installed electronic module.
13.1. Draining
Notice:
Do not drain the bath fluid while it is hot!
Check the temperature of the bath fluid prior to draining (by switching the unit on for
a short moment, for example).
Store and dispose the used bath fluid according to the laws for environmental
Draining
• Turn off the unit and disconnect the mains cable from the
power source.
• Place the Cryo-Compact Circulator near the rim of the table.
Use a suitabel vessel as recipient for the bath liquid
• Unscrew the drain tap and empty the unit completely.
• Tighten the drain tap.
