Julabo FC1200S - Connecting an External Sensor

Recirculating coolers
23
5.8. Connecting an external sensor
10.
9.
MIN
MAX
0
1
2
3
4
5
6
N
Connect an external temperature sensor for
measuring and controlling the temperature directly in
the external system.
(Control mode - see page 41).
ACTUAL SET
Connect a
Pt100 sensor (Order No. 8 981 003)
or
M+R Adapter with Pt100 sensor
(Order No. 8 981 020)
to connector "N"
(sensor calibration - see page 41).
