Julabo FC1200S - Page 43

Recirculating coolers
43
ACTUAL SET
h Set the external programmer to the lowest
temperature value.
i In the calibration level, select the item Ad
_
P and
set the lowest temperature value (example: -20
°C).
n Press the setpoint key (E).
Follow the instructions under section 6.3.1.
page 26.
o
p
q
j Do not alter any setting on either of the units as
long as the display "Ad_P" is blinking.
k The lowest programmer value of -20 °C, and the
highest value of 80 °C correspond now to the
respective values of the recirculating cooler.
Example:
Programmer Recirculating cooler
-99.9 °C -20 °C
- 50 °C
-10 °C
0 °C
0 °C
50 °C
10 °C
100 °C
20 °C
200 °C
40 °C
300 °C
60 °C
400 °C
80 °C
