Shaking Water Baths
35
11. Electrical connection
RS232C serial interface
This port can be used to connect a computer with an RS232C
cable for remote control of the waterbath.
Pin assignment:
Pin 1 RxD Receive Data
Pin 2 TxD Transmit Data
Pin 3 0 VD Signal GND
Use shielded cables only.
Accessories:
RS-232 interface connecting cable, terminated with 3-pin
Cinch plug and 9 hole subD socket. Length: 3.0 m.
Order No. 8 980 075
