JUMO cTRON 04 User Manual

17
3 Electrical connection
3.2 Electrical isolation
»
2300 V AC
»
30 V AC
50 V DC
»
2300 V AC
»
30 V AC
50 V DC
(1)
(2)
(3)
(7)
(6)
(5)
(4)
(1) Analog input
(2) Binary inputs/
Output K3
(Logics)
(3) Setup interface
(4) Voltage
supply
(5) RS485 interface
(6) Analog output
(7) Outputs K1, K2 and K4
(relay)
