7
1 Introduction
1.2 Type designation
Basic type
702071 Type 702071 (nominal dimension 48mm x 48mm)
1 analog input, 2 binary inputs (alternative to logic output and input
0/2…10V, resp.)
702072 Type 702072 (nominal dimension 48mm x 96mm)
1 analog input, 2 binary inputs (one binary input alternative to input
0/2…10V)
702074 Type 702074 (nominal dimension 96mm x 96mm)
1 analog input, 2 binary inputs (one binary input alternative to input
0/2…10V)
Basic type extensions
8 Standard with factory settings
9 Customer-specific programming according to
specifications
Output 1 - 2 - 3 - 4
1130 Relay - Relay - Logics 0/14V
1131 Relay - Relay - Logics 0/14V - Relay
1134 Relay - Relay - Logics 0/14V - Analog output
Voltage supply
23 AC 110…240V, 48…63Hz
25 AC/DC 20…30V, 48…63Hz
Interface
00 Without
53 Interface RS485 with
electrical isolation
/--- Type key
702071 / 8 - 1130 - 23 - 00 Example
