5 Operator level
30
Parameters
Depending on the configuration, the following values are displayed:
Symbol Meaning
SP 1
Set point value 1 (can be edited)
SP 2
Set point value 2 (can be edited), only when switching over to set
point value 2
v Chapter 7.7 „Binary functions“
SPr
Ramp set point value (only if configured)
v Chapter 7.3 „Ramp function“
InP1
Measured value of analog input 1
y
Output value
t1
Timer time (only if configured and timer is not running)
v Chapter 7.5 „Timer“
tL
Timer running time (only if timer runs)
v Chapter 7.5 „Timer“
tr
Residual timer running time (only if timer runs)
v Chapter 7.5 „Timer“
OC
Service counter display (only if service counter runs or as long as
a reached limit value was not reset)
v Chapter 7.8 „Display/Operation/Service counter“
