7 Configuration level
34
Analog selector
Some parameters in the Configuration level allow users to select from
a series of analog values. The list below shows all available signals.
TIP!
For activation of binary input 2 the setup program is re-
quired (Hardware assistant).
Value Description
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
deactivated
Analog input
Process value
current set point value
Ramp limit value
Ramp set point value
(reserved)
(reserved)
Set point value 1
Set point value 2
Controller output value (-100%…+100%)
Controller output 1 (0…+100%; e. g. „Heating“)
Controller output 2 (0…-100%; e. g. „Cooling“)
Timer run time (time unit of the timer)
Residual timer run time (time unit of the timer)
(reserved)
(reserved)
(reserved)
