JUMO cTRON 04 User Manual

39
7 Configuration level
Process value
for controller
CPr
(analog
selector)
Analog
input
Determines the source of the controller
process value.
v Page 34, Analog selector
Output value,
manual mode
(Setup)
-100…
+101
Defines the output value after switching to
manual mode.
101 = last output value
For modulating controllers:
0 = Actuator closes
100 = Actuator opens
101 = Actuator stops
Setting in the setup program (-> Controller
-> Output value, manual mode)
Output value at
Out of Range
(Setup)
-100…
0…
+101
Output value in the event of overrange or
underrange.
101 = last output value
For modulating controllers:
0 = Actuator closes
100 = Actuator opens
101 = Actuator stops
Setting in the setup program (-> Controller
-> Output value at Out of Range)
Manual mode
(Setup)
free
inhibited
If the manual mode is inhibited, it is not
possible to change to the manual mode
using the keys or the binary input.
Setting in the setup program (-> Controller
-> Manual mode)
Self-
optimization
(Setup)
free
inhibited
If self-optimization is inhibited, it cannot be
started using keys or the binary function.
v Chapter 8.3 „Self-optimization“
Setting in the setup program
(-> Controller -> Self-optimization)
Self-optimization is also inhibited, if the
parameter level is inhibited.
v Chapter 7.7 „Binary functions“
v Chapter 7.8 „Display/Operation/Service
counter“
Parameters Value/
Selection
Description
