JUMO cTRON 04 User Manual

7 Configuration level
44
ConF
-> LC -> LC1 , LC2 ->
Parameters Value/
Selection
Description
Function
FnCt
0
1
2
3
4
5
6
7
8
no function
lk1
lk2
lk3
lk4
lk5
lk6
lk7
lk8
Alarm value
AL
-1999…
0…
+9999
Alarm value (limit value) to be monitored
(see limit comparator functions lk1...lk8:
alarm value AL)
Alarm value range for lk1 and lk2: 0...9999
Hysteresis
HySt
0…
1…
9999
Hysteresis in respect to the alarm value
(see limit comparator functions lk1...lk8:
hysteresis HySt)
Response by
Out of Range
ACrA
0
1
Switching state in the event of overrange or
underrange („Out of Range“)
off
on
Limit
comparator
process value
LCPr
(analog
selector)
Process
value
Input variable for limit comparator
(see limit comparator functions lk1...lk8:
process value x)
Limit
comparator set
point value
LCSP
(analog
selector)
Current
set point
value
Set point value for limit comparator
(see limit comparator functions lk1...lk6:
set point value w)
