7 Configuration level
52
ConF
-> binF ->
Parameters Value/
Selection
Description
Binary inputs
b in1
b in2
1
1.
For activation of binary input 2 the setup program is required (Hardware
assistant).
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
no function
Start self-optimization
Abort self-optimization
Change to manual mode
Controller off (controller outputs are
switched off)
Switch on controller
Inhibit manual mode
Stop ramp
Abort ramp
Restart ramp
Set point value toggling:
0/Contact open=Set point value 1 active,
1/Contact closed= Set point value 2
active)
(reserved)
(reserved)
(reserved)
(reserved)
(reserved)
Key inhibit
Level inhibit:
The parameter and the configuration
level are inhibited.
Start of self-optimization is inhibited
Display off with key inhibit
(reserved)
Timer acknowledgement
Starting the timer
Timer abort
Timer stop
Timer start/abort
Limit
comparators
LC1
LC2
Timer signal
tF1
Ramp end
signal
rEnd
Tolerance band
signal, ramp
toLS
