3 Operation and visualisation
44
Example:
- Channel 3
- Presentation range: 0 — 100mm
- Limit comparator thresholds at 200 and 500°C
Example:
- Channel 2
- Presentation range limited to: 50 — 100mm
- Limit comparator threshold at 300V
