4 Configuration table
58
Range start: -9999 to +9999 Enter start of
measurement range
1
Range end: -9999 to +9999
Meas. span ≥ 100°C
for Type S, R, B ≥ 500°C
Enter end of
measurement range
1
Cold junction:
(temp. comp.)
INTERN Pt 100
EXT. CONST.
Select cold junction
Cold junct. temp.:
(comp. temp.)
Value range:
-50 to +100°C
Enter cold junction temp.,
if cold junction = EXT.
CONST.
Filter: 0.0 — 50.0sec Enter filter constant
Configuration level 1
➔ Measurement input
Type: Potentiometer
Characteristic: linear, X1, X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Connection: 2/3-wire
4-wire
Determine type of connec-
tion for the potentiometer
Start res. Ro: 0 ≤ Ro ≤ 4000Ω Enter start resistance
Res. range Rp: 6 ≤ Rp ≤ 4000Ω
Ro + Rp ≤ 4000Ω
Meas. span ≥ 6Ω
Enter measurement range
(resistance Rp)
Filter: 0.0 — 50.0sec Enter filter constant
Configuration level 1
➔ Measurement input
Type: res. transmitter
Characteristic: linear, X1, X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Start res. Ra: 0 ≤ Ra ≤ 4000Ω Enter start resistance
Res. range Rs: 6 ≤ Rs ≤ 4000Ω Enter measurement range
1. The limits for range start and range end differ according to the characteristic
Parameter Value/selection Description
