4 Configuration table
End res. Re: 0 ≤ Re ≤ 4000Ω
Ra + Rs + Re ≤ 4000Ω
Meas. span ≥ 6Ω
Enter end resistance
Filter: 0.0 — 50.0sec Enter filter constant
Configuration level 1
➔ Measurement input
Type: voltage
Characteristic: linear, Pt100, Pt100 JIS,
Pt500, Pt1000, Ni100, L, J,
U, T, K, E, N, S, R, B, X1,
X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Unit: mV, V
Range start: -9999 to +9999
-10V ≤ range start < 10V
Enter start of
measurement range
1
Range end: -9999 to +9999
-10V < range end ≤ 10V
Meas. span ≥ 5mV
Enter end of
measurement range
1
Temperature:
(dimension)
°C, °F (only for thermocouples
and resistance
thermometers)
Temp. start: -9999 to +9999 Enter start of temperature
range
1
(only for thermocouples
and resistance
thermometers)
Temp. end: -9999 to +9999
Measurement span
-Resistance
thermometer ≥ 15°C
- Thermocouples
≥ 100°C
- S, R, B ≥ 500°C
Enter end of temperature
range
1
(only for thermocouples
and resistance
thermometers)
Filter: 0.0 — 50.0sec Enter filter constant
Configuration level 1
➔ Measurement input
Type: current / shunt
Characteristic: linear, Pt 100, Pt 100 JIS,
Pt 500, Pt 1000, Ni 100, L,
J, U, T, K, E, N, S, R, B, X1,
X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Range start: -9999 to +9999
-20mA ≤ rge. start < 20mA
Enter start of measurement
range
1
1. The limits for range start (temp. start) and range end (temp. end) differ
according to the characteristic
Parameter Value/selection Description
