3 Operation - Configuration - Parameterization
3.2 Configuration (ConF)
Analog selector
With some parameters in the configuration level, the user can choose from a series of analog
values. The following list contains all available signals.
3.2.1 Analog input (InP)
ConF
-> InP ->
TIP!
The device will map out parameters unless the equipment level permits the function
assigned to the parameter. Factory settings appear in bold in the following table.
Value Description Value Description
0 Switched off 7 Setpoint 2
1 Analog input 8 Output level display
(-100 % to +100 %)
2 Actual value 9 Controller output 1 (e.g. heating, 
output level 0 to +100 %)
3 Current setpoint 10 Controller output 2 (e.g. cooling, 
output level 0 to -100 %)
4 Ramp end value 11 Timer run time (time unit of the
timer)
5 (reserved) 12 Timer residual time (time unit of the
timer)
6Setpoint 1
Parameters Value Description Value Description
Probe type
SEnS
RTD temperature probe: Thermocouples:
0 Pt100 3-wire 9 NiCr-Ni K
1 Pt1000 3-wire 10 Pt10Rh-Pt S
2 Pt100 2-wire 11 Pt13Rh-Pt R
3 Pt1000 2-wire 12 NiCrSi-NiSi N
4 KTY 2 wire 13 NiCr-CuNi E
5 Cu-50 3-wire Standard signals:
Thermocouples: 14 0 to 20 mA
6 Cu-CuNi T 15 4 to 20 mA
7 Fe-CuNi J 16 0 to 10 V
8 Fe-CuNi L
When selecting "0 to 10 V“, binary input bin1 is inactive.
