3 Operation - Configuration - Parameterization
3.2.6 Outputs (OutL, OutA)
The configuration of the device outputs is subdivided in binary outputs (OutL) and analog output
(OutA). The switching states of binary outputs 1 to 3 (5) are displayed by LEDs K1 to K3 (K5) (LED
is lit = output active).
Binary outputs
The device is equipped with a relay output (N/O, output 1) as standard and can be optionally
equipped with two (four) additional binary outputs (relay or logic output; outputs 2 to 5).
ConF -> OutL ->
Analog output
The device can be optionally equipped with an analog output (output 2).
ConF -> OutA ->
Parameters Value Description
Output 1 ... 5
Out1
Out2
Out3
Out4
Out5
0 Output not active (factory setting for Out2 ... Out5)
1 Controller output 1 (factory setting for Out1)
2 Controller output 2
3 Binary input
4 Limit value monitoring 1
5 Limit value monitoring 2
6 Timer signal
(Setup program: The output signal can be inverted.)
Parameters Value Description
Function
FnCt
9 Function of the output; 9 = Controller output 1
Ö
Ö
"Analog selector", page 15
Type of signal
SiGn
Physical output signal
0 0 ... 20 mA
1 4 ... 20 mA
2 0 ... 10 V
Value at
Out-of-Range
rOut
0 ... 101 Signal (in percent) at overrange or underrange
101 = last output signal
Zero point
0Pnt
-1999 ...
0 ...
+9999
Value range of the output variable for the physical output sig-
nal
End value
End
-1999 ...
100 ...
+9999
