JUMO Quantrol LC100 - Cleaning the Device Front

25
4 Supplement
LC300
Minimum spacing of panel cut-outs
4.1.2 Cleaning the device front
The device front panel can be cleaned with commercial cleaning and rinsing agents. It has a
limited resistance to organic solvents (such as ethyl alcohol, turpentine substitute, P1, xylol and
similar). Do not use high-pressure cleaning equipment.
(1) Setup interface (USB)
on the device bottom
(2) Panel cut-out
Type without USB cable with USB cable
horizontal vertical horizontal vertical
LC100 11 mm 30 mm 11 mm 65 mm
LC200 22 mm 30 mm 22 mm 65 mm
LC300 22 mm 30 mm 22 mm 65 mm
92
+0.8
92
+0.8
(1)
(2)
