4 Technical Specifications
Z
The technical specification is given according to the German guideline "Type sheets
for industrial trucks". Technical modifications and additions reserved.
4.1 Performance data
AMW 22 / AMW 22p /
AMW 22ps
Q Rated capacity 2200 kg
c Load centre distance 600 mm
x Load distance 890 mm
Lowering speed with / without load 90/20 mm/s
4.2 Weighing System Weight Display
AMW 22 and AMW 22p
Weight range Resolution of weight display
AMW 22 AMW 22p
(t)
1)
AMW 22p
(o)
1)
AMW 22p
Calibrated (o)
1)
0 to 200 kg 1.0 kg 0.2 kg 0.1 kg 0.5 kg (o)
200 to 500 kg 0.5 kg 0.2 kg
500 - 2000 kg (t)
1.0 kg
0.5 kg 1.0 kg
500 - 2200 kg (o)
AMW 22ps (from year of manufacture 2020)
Weight range Resolution of weight display
AMW 22ps (t)
1)
AMW 22ps
Calibrated (o)
1)
0 to 200 kg 0.2 kg 0.5 kg
200 to 500 kg 0.5 kg
500 - 2000 kg (t)
1.0 kg 1.0 kg
500 - 2200 kg (o)
1) Multi-range display: The resolution of the weight display depends on the weight.
During weighing out, the resolution does not change on passing the boundary to the
next lower weight range.
14
11.19 en-GB
