4.4 Dimensions
s
e
W
a
x
h
14
b
11
b
10
b
1
= b
5
h
3
h
13
l
1
l
6
l
2
l
m
2
674 (AMW 22p / AMW 22ps)
y
c
Q
104°
104°
a/2=100
a/2=100
Ast = W
a
+l
6
-x+a
Designation AMW 22 / AMW 22p /
AMW 22ps
h
3
Lift
122 mm
h
13
Lowered height
86 mm
h
14
Height of tiller handle
1234 mm
y Wheelbase 1110 mm
s/e/l Fork dimensions 62/170/1150 mm
l
1
Overall length 1546
mm
l
2
Length to fork face
396 mm
16
