Designation AMW 22 / AMW 22p /
AMW 22ps
b
1
Overall width
540 mm
b
5
Outer fork distance
540 mm
b
10
Track width, front
109 mm
b
11
Track width, rear
370 mm
Ast Working aisle width 1000x1200 transv. 1763 mm
Ast Aisle width 800x1200 length. 1813 mm
Wa Turning radius 1303 mm
4.5 Weights
Designation AMW 22 / AMW 22p /
AMW 22ps
Net weight 99/102 kg
Axle load, w.o. load front/rear 61/38 kg
Axle load, w. load front/rear (AMW 22) 578/1721 kg
4.6 Batteries
Truck Battery type Voltage/capacity
AMW 22 Alkaline (type AA) 4x1.5 V
AMW 22p Lead-gel battery
(rechargeable)
12 V/1.2 Ah
AMW 22ps Lithium-ion battery
(rechargeable)
14.8 V/5 Ah
4.7 Tyre type
AMW 22 / AMW 22p /
AMW 22ps
Tyre size, front Ø 170 x 50 mm
Tyre size, rear Ø 82 x 96 mm
Tyre size, rear (tandem wheels) Ø 82 x 62 mm
17
11.19 en-GB
