4.9.3.8 Printing weighing data
If the weighing system is equipped with a printer, current weighing data and entered
data can be printed. The date and time are only printed if the option has been
installed.
On the printout, the weights and corresponding data appear as follows:
Weight Label
Code number CODE
Gross weight [kg] or [lb] B/G
Net weight [kg] or [lb] N
Manually entered tare [kg] or [lb] PT
Total weight Tot.
Date format (year/month/day) YY/MM/DD
Time in 24h format (hours/minutes) HH:MM
Example 1:
Standard printout without
code number
Example 2:
Standard printout with code
number
CODE 12345
B/G 1234.5 kg B/G 1234.5 kg
T 34.5 kg T 34.5 kg
N 1200.0 kg N 1200.0 kg
No. 1 No. 1
19/07/03 17:45 19/07/03 17:45
Example 3:
Total weight (always without
code)
Tot. B/G 1234.5 kg
Tot. T 34.5 kg
Tot. N 1200.0 kg
No. 1
Tot. No. 999
19/07/03 17:45
87
11.19 en-GB
