Jungheinrich EMC 110/B 10 User Manual

B 4
0708.GB
3 Technical data - standard version
A
Technical data specified according to VDI 2198.
Technical data are subject to alteration and additions.
3.1 Performance data for standard trucks
3.2 Dimensions
* Ast includes a safety distance of 200 mm
** Can be adjusted in steps of 50 mm
Designation EMC / EMB
Q Rated load capacity 1000 kg
C Load centre 600 mm
Travelling speed with / without load 3.5 / 4 km/h
Lifting speed with / without load 8.0 / 11.0 cm/s
Lowering speed with / without load 20 / 7 cm/s
Designation Standard EMC
Broad version
EMB
h
1
Hoist frame height 1970 1970 mm
h
3
Lifting height 1560/2000 1560/2000 mm
h
13
Load lifting device lowered 90 90 mm
y
Wheel base, load part
lowered
1170 1170 mm
l
1
Truck length 1710 1710 mm
Distance
drive wheel <-> front chass.
150 150 mm
l
2
Front section length 530 530 mm
b
1
Truck width 800 - mm
Wa Turning radius 1405 1405 mm
Ast*
Aisle width
1000x1200 in transversal dir.
2241 2340 mm
Ast*
Aisle width
800x1200 in longitudinal dir.
2178 2190 mm
b
4
**
Max. distance between
wheel arms, inside
- 970 - 1270 mm
b
1
/b
2
**
Max. distance between
wheel arms, outside
- 1170 - 1470 mm
b
5
Distance between the forks,
outside
540 540 or 660 mm
e Fork width 160 160 mm
B 4
0708.GB
3 Technical data - standard version
A
Technical data specified according to VDI 2198.
Technical data are subject to alteration and additions.
3.1 Performance data for standard trucks
3.2 Dimensions
* Ast includes a safety distance of 200 mm
** Can be adjusted in steps of 50 mm
Designation EMC / EMB
Q Rated load capacity 1000 kg
C Load centre 600 mm
Travelling speed with / without load 3.5 / 4 km/h
Lifting speed with / without load 8.0 / 11.0 cm/s
Lowering speed with / without load 20 / 7 cm/s
Designation Standard EMC
Broad version
EMB
h
1
Hoist frame height 1970 1970 mm
h
3
Lifting height 1560/2000 1560/2000 mm
h
13
Load lifting device lowered 90 90 mm
y
Wheel base, load part
lowered
1170 1170 mm
l
1
Truck length 1710 1710 mm
Distance
drive wheel <-> front chass.
150 150 mm
l
2
Front section length 530 530 mm
b
1
Truck width 800 - mm
Wa Turning radius 1405 1405 mm
Ast*
Aisle width
1000x1200 in transversal dir.
2241 2340 mm
Ast*
Aisle width
800x1200 in longitudinal dir.
2178 2190 mm
b
4
**
Max. distance between
wheel arms, inside
- 970 - 1270 mm
b
1
/b
2
**
Max. distance between
wheel arms, outside
- 1170 - 1470 mm
b
5
Distance between the forks,
outside
540 540 or 660 mm
e Fork width 160 160 mm
